Pneumatic printing machine
Contact Us
Inquiry
General Description
The Flat Screen printing machine is the latest product produced.It’s designed on the basis of different screen machine type’s advantages, and reflects the screen printing development trends with high speed ,easy operation and compact size. The machine adopts complete adjustment, control system and new structure to enhance property.
Application
Application:the machine can be applied to the printing on substrates from thin
plastics, paper, ceramics, metal, glass, rubber, etc, to fabrics; its function is unique
and quality stable. The machine is widely applied in the special printing in
industry, commerce, packaging, decoration, art, and etc.
feature:
1.PLC control, user-friendly interface, clear function display and easy operation.
2.The scraper air hose is covered with a protective chain belt to make the operating space more tidy.
3.Two-color flat screen printing machine, drying by infrared rays. It is suitable for 6 stations with different types of oil, and the indexer is driven by a motor to ensure the smooth and accurate operation of the machine.
4.The angle and height of the squeegee and the ink-returning knife can be adjusted to ensure continuous printing pressure. When registering with color printing, the second color silk screen template can be adjusted accurately.
Parameter
| Model | TX-130F5 | TX-130F8 | TX-130F83 | TX-130F103 | TX-F104 | TX-130F83L | TX-300F6 |
| Max printing size | 100*130mm | 100*130mm | 100*130mm | 100*130mm | 100*130mm | 200*130mm | 300*300mm |
| Max printing speed | 900pcs/hr | 900pcs/hr | 900pcs/hr | 900pcs/hr | 900pcs/hr | 900pcs/hr | 900pcs/hr |
| Related powder | 7kw | 7kw | 7kw | 7kw | 7kw | 7kw | 7kw |
| Related voltage | Three-phase four wire 380V 50Hz | Three-phase four wire 380V 50Hz | Three-phase four wire 380V 50Hz | Three-phase four wire 380V 50Hz | Three-phase four wire 380V 50Hz | Three-phase four wire 380V 50Hz | Three-phase four wire 380V 50Hz |
| Related current | 40A | 40A | 40A | 40A | 40A | 40A | 40A |
| Air Consumption | 86Litre/min | 86Litre/min | 86Litre/min | 86Litre/min | 86Litre/min | 86Litre/min | 86Litre/min |
| Outline dimension | 1610*610*156mm | 1610*610*156mm | 1610*610*156mm | 1610*610*156mm | 1610*610*156mm | 1610*610*156mm | 1610*610*156mm |
| Weight | 285kg | 285kg | 285kg | 285kg | 285kg | 285kg | 285kg |
| Model | TX-130F5L3 | TX-130F8L3 | TX-130F83L3 | TX-130F103L3 | TX-F104L3 |
| Max printing size | 200*203mm | 200*203mm | 200*203mm | 200*203mm | 200*203mm |
| Max printing speed | 900pcs/hr | 900pcs/hr | 900pcs/hr | 900pcs/hr | 900pcs/hr |
| Related powder | 7kw | 7kw | 7kw | 7kw | 7kw |
| Related voltage | Three-phase four wire 380V 50Hz | Three-phase four wire 380V 50Hz | Three-phase four wire 380V 50Hz | Three-phase four wire 380V 50Hz | Three-phase four wire 380V 50Hz |
| Related current | 40A | 40A | 40A | 40A | 40A |
| Air Consumption | 86Litre/min | 86Litre/min | 86Litre/min | 86Litre/min | 86Litre/min |
| Outline dimension | 1610*610*156mm | 1610*610*156mm | 1610*610*156mm | 1610*610*156mm | 1610*610*156mm |
| Weight | 285kg | 285kg | 285kg | 285kg | 285kg |
pLC: Mitsubishi
New screen: Weilun
Solenoid valve: Adek
Rodless cylinder: SMC
